Hydraulic Flow Amplifier
This hydraulic flow amplifier features a compact structure and large steering capacity. It converts a small flow into a large flow to simplify operation.
Technical Specifications
Product Overview
High-Efficiency Hydraulic Flow Amplification
This hydraulic flow amplifier is designed to optimize heavy machinery performance by converting small pilot flows into larger output flows, significantly simplifying operation. Its compact structure minimizes hydraulic shock while maximizing steering capacity and energy efficiency through load-sensing pilot control. Ideal for demanding industrial environments, it ensures precise control and full utilization of system energy.
Key Performance Metrics
Performance Metrics
25 MPa
Nominal Pressure
160 L/min
Nominal Flow Rate
21 kg
Unit Weight
Technical Specifications
- Output Flow Range
- 80-145 L/min
- Operating Temperature Range
- -20°C to 100°C
- Viscosity Range
- 10-380 mm²/s
Fluid Requirements
- Recommended Hydraulic Oil
- Mineral oil (HL, HLP) conforming to DIN 51 524
- Fluid Cleanliness Standards
- GB/T 14039-93 Level 19/16NAS 1638 Level 10
Applications
Compatible Machinery
LoadersBulldozersExcavatorsAgricultural MachineryMaterial Handling Equipment
Features
Key Features
- Compact structure with high steering capacity
- Load-sensing pilot connection control
- Minimizes hydraulic shock during operation
- Energy-saving design for total power utilization
- Improves system efficiency by increasing oil flow to the steering cylinder
