Hydraulic Accumulator Filling Valve
This hydraulic accumulator filling valve uses the main hydraulic system to generate power. It achieves full hydraulic braking of the vehicle by filling the accumulator to maintain constant brake pressure.
Technical Specifications
Overview
Hydraulic Accumulator Filling Valve
This hydraulic accumulator filling valve is engineered to integrate seamlessly into main hydraulic systems to generate power and facilitate full hydraulic braking. It features an integrated one-way valve and pressure compensation valve, ensuring the accumulator maintains consistent brake pressure. Designed for reliability and compactness, this unit effectively reduces pump cycle times and can be installed at a distance from the brake valve.
Performance Metrics
Maximum Pressure
20 MPa
Maximum Pressure
Maximum Flow
70 L/min
Maximum Flow
Technical Specifications
- Liquid Filling Flow
- 6～17 MPa
- Hydraulic Fluid
- Mineral oil (HL, HLP) in accordance with DIN 51 524
- Operating Temperature
- -20 to 100 °C
- Viscosity Range
- 10～380 mm²/s
- Oil Cleanliness
- GB/T 14039-93 19/16 or NAS 1638 level 10
- Weight
- 6.5 Kg
Applications
- Compatible Machinery
- GraderWheel excavatorForkliftWheel loadersHoisting MachineryOther walking machinery
