Ultrathin Heat Recovery Ventilation Unit
This ultrathin heat recovery unit features a high-efficiency, energy-saving motor and achieves PM2.5 filtration efficiency up to 99.3%. Its slim profile allows for installation in tight spaces, making it suitable for modern buildings.
Technical Specifications
Product Overview
High-Efficiency Energy Recovery Ventilation
This ultrathin ventilation unit is designed to provide optimal indoor air quality by continuously exchanging stale indoor air with fresh, filtered outdoor air. By utilizing an advanced heat exchange system, it effectively preheats or precools incoming air using energy recovered from the exhaust stream, significantly reducing heating and cooling demands. The unit is engineered for easy installation in space-constrained environments while providing reliable, energy-saving performance.
Technical Specifications
- Heat Exchange Efficiency
- 73 %
- Filtration Grade
- HEPA Grade 12
- PM2.5 Filtration Efficiency
- 99.3 %
Control & Operation
- User Interface
- Large LCD Touch Screen
- Control Options
- AutomaticManualProgrammable
System Components
Key Components
- Supply & Exhaust Fans
- Air Heat Exchanger
- High-Efficiency Air Filters
- Programmable Control System
- Energy-Saving Motor
Airflow Port Designations
| Port Label | Function |
|---|---|
| SA | Supply Air |
| EA | Exhaust Air |
| OA | Outdoor Air |
| RA | Return Air |
