Twin Cylinder Horizontal Engine
This V-Twin engine delivers high power, making it suitable for heavy commercial applications. Its displacement ranges from 679cc to 999cc, providing strong and reliable power.
Technical Specifications
Overview
High-Performance Twin Cylinder Engine
This twin-cylinder horizontal engine is engineered for heavy commercial applications, delivering robust and reliable power. Designed for demanding environments, it features a high-capacity air filter and an optimized combustion chamber for efficient operation. It serves as an ideal power source for industrial equipment such as generators and pumps.
Performance Metrics
Rated Power
24 Kw
Rated Power
33 HP
Rated Power
- Maximum Torque
- 71 N.m
- Max Output Speed
- 3900 r/min
Technical Specifications
- Displacement
- 679cc - 999cc
- Cylinder Bore x Stroke
- 90 x 78.5 mm
- Idle Speed
- 1650 ± 150 r/min
Maintenance & Operation
- Starting System
- Electrical
- Engine Oil Capacity
- 2.5 L
- Recommended Oil
- SAE 10W-30
Application Features
- Engine Configuration
- V-TwinHorizontalHigh-Power
