IP65 Waterproof LED Doorbell Switch
This IP65 rated doorbell switch is waterproof, shockproof, and dustproof. It features an integrated LED and screw-less terminals for easy installation.
Technical Specifications
Overview
Robust Outdoor Connectivity
This IP65-rated surface-mounted doorbell switch is engineered for demanding environments, offering superior protection against dust, water jets, and environmental contaminants. Designed with user-friendly features like screw-less terminals and a quick-lock mechanism, it ensures efficient installation and reliable performance. The unit features an integrated white LED indicator for clear visibility and is constructed from durable, fire-resistant thermoplastic materials suitable for both indoor and outdoor applications.
Technical Specifications
Ingress Protection
IP65
- Rated Voltage
- 250 V
- Rated Current
- 10 AX
- Network Frequency
- 50/60Hz
- Switch Function
- 1 way
Design & Installation
- Mounting Type
- Surface mounting
- Fixing Mode
- Screw-less terminal
- Wire Stripping Length
- 12 mm
- Enclosure Outlet Compatibility
- 4-8mm8-12mm12-16mm16-20mm
Features
Key Advantages
- Dust and water spray resistant (IP65)
- Tamper-resistant system for child safety
- Halogen-free and fire-resistant thermoplastic construction
- Quick-lock structure (90-degree rotation)
- Modular design for easy installation and component replacement
- High-transmittance LED indicator
- Materials
- TPEPPPC-UV
