High Purity Molybdenum Sheet for Electrical Components
This high-purity molybdenum sheet is designed for electrical components and high-temperature applications. It exhibits good thermal conductivity and a high melting point.
Technical Specifications
Overview
High-Performance Molybdenum Sheet
This high-purity molybdenum sheet is engineered for demanding industrial applications requiring exceptional thermal stability and durability. Manufactured via powder metallurgy, it offers superior thermal conductivity and a high melting point, making it an ideal choice for electrical light source components, vacuum furnace heat shields, and medical facility equipment. The material is available in various grades and surface finishes to meet precise engineering requirements.
Material Properties
- Density
- 10.2 g/cm3
- Purity
- >= 99.95%
- Available Material Grades
- Mo1Mo2TZMMoLaMoCu
Technical Specifications
Surface Finish
BlackGroundCold Rolled
Typical Applications
- Electrical light source parts
- Heat shields
- High-temperature furnace bodies
- W-boats
- Tungsten sputtering targets
- Medical facilities
- Production Technique
- Powder Metallurgy
- Standard
- ASTM B-386
Chemical Composition
Chemical Composition Limits
| Grade | C (Max %) | O (Max %) | Fe (Max %) |
|---|---|---|---|
| 360 | 0.03 | 0.002 | 0.01 |
| 361 | 0.01 | 0.007 | 0.01 |
