Electric Vehicle Recovery Winch with Synthetic Rope
This electric winch is designed for vehicle recovery and heavy-duty pulling applications. It features a robust motor, durable construction, a high-strength synthetic rope, and a remote control for safe and convenient operation.
Technical Specifications
Overview
High-Performance Recovery Winch
This 9500lbs electric recovery winch is engineered for heavy-duty pulling and off-road vehicle recovery. Featuring a robust 6.6HP motor and advanced waterproof construction with anti-UV coating, it provides reliable performance in harsh environmental conditions. The system includes an automatic drum braking device for safety and is compatible with a wide range of vehicles, including pickups, SUVs, and dedicated off-road models.
Performance Metrics
Rated Line Pull
9,500 lbs
Rated Line Pull
6.6 HP
Motor Power
Technical Specifications
Cable Specifications
| Cable Type | Diameter | Length |
|---|---|---|
| Synthetic Rope | 9.4 mm | 28.5 m |
| Steel Wire Rope | 8 mm | 28.5 m |
- Safety & Protection
- Waterproof StructureAnti-UV CoatingAutomatic Braking System
Installation & Compatibility
Suitable Vehicle Types
- JEEP Wrangler
- Pickup Trucks
- Hardcore SUVs
- Vehicles with adequate mounting space
Installation Requirements
| Parameter | Detail |
|---|---|
| Estimated Time | 40 min |
| Mounting Locations | Front bumper, rear, or quick-mount bracket |
Logistics
- Packaging Dimensions
- 66 x 32 x 26 cm
