Diesel Engine Fuel Injector Nozzle DLLA160P1308
This diesel fuel injector nozzle is designed for common rail systems. Its geometry strongly influences fuel atomization and spray processes, impacting engine performance and emissions.
Technical Specifications
Overview
High-Precision Diesel Injection
The DLLA160P1308 is a high-precision fuel injector nozzle designed for modern common rail diesel systems. It plays a critical role in fuel atomization and spray processes, which directly influence engine performance and emission levels. Engineered for durability with steel body construction, this component ensures a reliable seal for the combustion chamber while optimizing fuel efficiency.
Technical Specifications
Key Performance Metrics
0.04 kg
Net Weight
6 Months
Warranty
- Body Material
- Steel
- Cylinder Compatibility
- Multi-cylinder
- Carburettor Type
- Downdraft
- Fuel Type
- Diesel
- HS Code
- 84099199
Compliance & Quality
- Quality Certifications
- ISO9001TS16949ISO 9001:2008SGS
Logistics
- Transport Package
- Diversified Neutral Packing
Reference Data
Injector Nozzle Reference Table
| Type | Reference No. | Stumping No. |
|---|---|---|
| DN_PDN | 105007-1120 | DN0PDN112 |
| DN_PDN | 093400-8220 | DN0PDN121 |
| DN_PD | 093400-5571 | DN4PD57 |
| P | 093400-5500 | DLLA160P50 |
| DN_SD | 0 434 250 063 | DN0SD193 |
| S | 0 433 271 376 | DLLA149S774 |
| S | 5621599 | DLL150S6556 |
| DN-S | DNOS34-G | DNOS34 |
