Continuous Slot Screen for Filtration
These continuous slot screens offer non-clogging capabilities and high abrasion resistance. Their design ensures efficient filtration, energy saving, and a long service life.
Technical Specifications
Product Overview
Continuous Slot Wedge Wire Screen
This continuous slot wedge wire screen is engineered for superior filtration performance in demanding environments such as water wells and industrial separation processes. By wrapping cold-drawn V-shaped profile wires around a framework of longitudinal support rods, the design creates a non-clogging, self-cleaning surface that minimizes friction losses. This construction offers a significantly larger open area compared to traditional perforated or bridge screens, resulting in higher flow rates and increased longevity for pumping equipment.
Technical Specifications
Slot Openings
- 0.15
- 0.25
- 0.5
- 0.75
- 1
- 1.5
- 2
- 3
- Available Diameters (NB)
- 1.5"2"3"4"6"8"10"12"14"16"
- Available Lengths
- 3 Meters6 Meters
Performance Metrics
Open Area Efficiency
35 %
Average Open Area
70 %
Maximum Open Area
Construction & Materials
Material Options
Low Carbon Galvanized Steel (LCG)Stainless Steel (SS-304)
- End Connections
- Plain beveled ends for butt welding or threaded
Application Suitability
Suitable Well Depths
- Up to 300 ft.
- Up to 600 ft.
- Up to 900 ft.
- Up to 1500 ft.
