Commercial Air Handling Unit for HVAC Systems
An air handling unit regulates and circulates air within a heating, ventilating, and air-conditioning (HVAC) system. The unit is a large metal box containing a blower, heating or cooling elements, filter racks, sound attenuates, and dampers.
Technical Specifications
Product Overview
Professional Commercial Air Handling Unit
This high-performance commercial air handling unit is engineered for demanding HVAC environments, including industrial, medical, and clean room applications. It features robust construction with advanced heat exchange technology, offering precise temperature control and efficient air circulation. Designed for reliability, the system incorporates comprehensive safety protections, including high/low-pressure switches, anti-frost, and power phase sequence monitoring.
Performance Metrics
Cooling Capacity Range
3.9 kW
Minimum Cooling
9.03 kW
Maximum Cooling
Heating Capacity Range
4.25 kW
Minimum Heating
9.23 kW
Maximum Heating
Technical Specifications
- Refrigerant
- R410A
- Heat Exchanger Types
- Copper-Fin-Coil (Air Side)Plate Type (Water Side)
- Water Connection
- DN40 (Soft Connection)
- Max Pressure
- 1 MPa
Electrical Requirements
Safety Protections
- High/low-pressure switch
- Anti-frost protection
- Water-flow switch
- Over-load protection
- Power phases sequence protection
- Power Supply
- 380V / 3Ph / 50Hz
Dimensions and Weight
Unit Dimensions & Weight
| Model Variant | Dimensions (L×W×H) | Net Weight |
|---|---|---|
| TFNP(14)ADA | 1082x435x1456 mm | 111 |
| TFNP(16)ADA | 1082x435x1456 mm | 120 |
| TFNP(21.5)ADA | 1620x1034x2041 mm | 270 |
| TFNP(24.8)ADA | 1620x1034x2041 mm | 290 |
