Camlock Garden Hose Connector
This camlock coupling is designed for garden hose applications, providing a secure and leak-proof connection. The cam-locking mechanism allows for quick and easy attachment and detachment of hoses.
Technical Specifications
Overview
Aluminum Camlock Quick Connect Coupling
This aluminum camlock coupling is designed for efficient, tool-free connection and disconnection of pipes and hoses. Engineered for durability and economy, it provides a secure, leak-proof seal for fluids, powders, and pellets. Ideal for a wide range of industrial and agricultural applications, this fitting offers significant time savings over traditional threaded or flanged connections.
Technical Specifications
- Body Material
- Aluminum
- Available Sizes
- 1/2" to 8"
- Max Working Pressure
- 250 psi
- Operating Temperature
- -150°F to +250°F
- Standards
- A-A-59326MIL-C-27487DIN 2828
Components & Materials
Component Materials
| Component | Material Options |
|---|---|
| Pins, Rings, Safety Clip | Carbon steel (plated) or Stainless steel |
| Handles | Brass or Stainless steel |
| Seal | NBR, BUNA, EPDM, VITON |
Logistics & Ordering
Payment Terms
- T/T
- L/C
- 30% deposit
- Lead Time
- 30 days from signed order
- Shipping Port
- FOB Qingdao
