Brushless DC Motor for Ventilation
This brushless DC motor is designed for ventilation applications. It features high speed, low noise, high power, and energy-saving capabilities.
Technical Specifications
Overview
High-Efficiency Ventilation Solutions
These brushless DC motors are engineered for superior performance in ventilation applications, offering a significant upgrade over traditional motor solutions. Designed for residential, commercial, and industrial settings, they provide high speed, low noise, and exceptional power efficiency to support energy-saving initiatives. With a focus on long-lasting durability, these motors are an ideal choice for high-standard ventilation systems.
- Key Features
- High SpeedLow NoiseHigh PowerElectronic ControlEnergy SavingHigh EfficiencyLong-lasting Durability
Customization
Customization Available
- Voltage
- Frequency
- Shaft Elongation
Technical Specifications
Model Performance Data
| Model | Voltage (V) | Input Power (W) | Current (A) | Insulation |
|---|---|---|---|---|
| DC8240-001 | 230 | 130 | 0.565 | B |
| DC8230-001 | 230 | 110 | 0.478 | F |
| DC9215-001 | 230 | 100 | 0.434 | F |
| DC9225-001 | 230 | 150 | 0.651 | F |
| DC9240-001 | 230 | 200 | 0.868 | F |
| DC7113-001 | 230 | 50 | 0.217 | F |
| DC7125-001 | 230 | 80 | 0.347 | F |
| DC7130-001 | 230 | 100 | 0.434 | F |
| DC18230-001 | 230 | 120 | 0.521 | F |
| DC18260-001 | 230 | 250 | 1.085 | F |
