Belt Driven Screw Air Compressor
This belt driven screw air compressor is designed for industrial use. It features an energy-saving design and a multi-functional electronic controller.
Technical Specifications
Overview
High-Efficiency Belt-Driven Screw Compressor
This industrial-grade belt-driven screw air compressor is engineered for reliability, combining German technology with an efficient design to deliver optimized air output. The unit features an energy-saving automated load management system and a noise-dampening enclosure for quiet operation below 68dB. Built for versatility, it is fully compliant with CE and ISO 9001 quality standards, ensuring robust performance for diverse global industrial requirements.
Certifications & Warranty
Warranty Coverage
- 1 year for the entire machine
- 3 years for the air end
- Certifications
- ISO 9001CE
Operational Performance
Noise Level
68 dB
Maximum Noise Threshold
- Compression Stage
- Single stage
Technical Specifications
Performance by Model
| Model | FAD/Pressure (m3/min/Mpa) |
|---|---|
| AH-10A | 1.2/0.7, 1.1/0.8, 0.9/1.0, 0.7/1.2 |
| AH-15A | 1.6/0.7, 1.5/0.8, 1.3/1.0, 1.1/1.2 |
| AH-20A | 2.5/0.7, 2.3/0.8, 2.1/1.0, 1.9/1.2 |
| AH-25A | 3.2/0.7, 2.9/0.8, 2.6/1.0, 2.2/1.2 |
| AH-30A | 3.8/0.7, 3.6/0.8, 3.2/1.0, 2.8/1.2 |
| AH-40A | 5.2/0.7, 5.0/0.8, 4.5/1.0, 3.8/1.2 |
| AH-50A | 6.8/0.7, 6.2/0.8, 5.6/1.0, 4.9/1.2 |
| AH-60A | 7.3/0.7, 7.0/0.8, 6.0/1.0, 5.6/1.2 |
| AH-75A | 10.0/0.7, 9.1/0.8, 8.5/1.0, 7.6/1.2 |
Electrical Compatibility
Voltage & Frequency Options
- 380V, 3phase, 50Hz
- 420V, 3phase, 50Hz
- 380V, 3phase, 60Hz
- 220V, 3phase, 60Hz
