Autoclaved Aerated Concrete AAC Blocks
Autoclaved aerated concrete (AAC) blocks are lightweight, precast building materials suitable for various construction applications. These cement boards provide excellent insulation, fire resistance, and are easy to install.
Technical Specifications
Product Overview
Sustainable High-Performance Construction
Autoclaved Aerated Concrete (AAC) is a lightweight, multi-cellular construction material designed to replace traditional clay bricks. It offers superior heat insulation, sound resistance, and earthquake resilience while being environmentally friendly by utilizing recycled fly ash. Its high plasticity allows for diverse shapes and sizes, making it a versatile choice for modern green building projects.
Key Features
- Performance Benefits
- Light WeightHeat InsulationSound ResistanceEarthquake ResistanceFire ResistantEasy Processability
Composition
Raw Materials
- Silicon material (Silica sand or recycled Fly ash)
- Calcium material (Lime, Portland cement)
- Foaming additive (Aluminum powder)
Technical Specifications
Model Capacity & Requirements
| Model | Capacity (m³/year) | Block Size (m³) | Power (kw) | Workshop Area (m²) |
|---|---|---|---|---|
| HIM-AAC-10 | 100,000 | 4.2x1.2x0.6 | 800 | 2,500 |
| HIM-AAC-15 | 150,000 | 4.2x1.5x0.6 | 900 | 3,000 |
| HIM-AAC-20 | 200,000 | 4.8x1.2x0.6 | 1,100 | 4,000 |
| HIM-AAC-30 | 300,000 | 6.0x1.2x0.6 | 1,300 | 5,000 |
| HIM-AAC-45 | 450,000 | 6.0x1.5x0.6 | 5,400 | 6,000 |
Manufacturing Process
Production Scale
1,500 m³/day
Max Daily Capacity
40,000 m²
Max Plant Area
Sustainability
- Eco-Friendly Material
- Yes
