Aluminum Welding Wire
Aluminum welding wire is precision-drawn for consistent diameter and smooth feeding, ensuring reliable arc stability. It provides excellent corrosion resistance and high tensile strength welds for welding aluminum alloys in various industries.
Technical Specifications
Overview
High-Performance Aluminum Welding Solutions
This premium aluminum welding wire is engineered for superior performance in both MIG and TIG welding processes. Featuring a shaved and lubricated surface, it ensures exceptional feedability and arc stability with minimal spatter. Available in over twenty different alloys, it provides excellent corrosion resistance and high tensile strength for demanding applications in automotive, aerospace, and general fabrication.
Key Features
Performance Highlights
20 +
Available Alloys
1,000 mm
Max TIG Length
15 kg
Max Spool Weight
Technical Specifications
Common Alloy Types
- ER1100
- ER4043
- ER4047
- ER5183
- ER5356
- ER5554
- ER5556
- Welding Processes
- MIGTIG
- Surface Treatment
- Shaved and lubricated for improved feedability
MIG Welding Data
Spool Standards
D100D200D300K300D355
MIG Wire Diameters
- 0.8
- 0.9
- 1
- 1.2
- 1.6
- 2
TIG Welding Data
TIG Wire Diameters
- 1.6
- 2
- 2.4
- 3.2
- 4
- 5
- Available Rod Lengths
- 914mm1000mm
Chemical Composition
Chemical Composition by Type
| Type | Si (%) | Mg (%) | Anodizing Color |
|---|---|---|---|
| ER1100 | 0.25 | 0.05 | Gold |
| ER4043 | 4.7-5.3 | 0.05 | Gray |
| ER5356 | 0.1 | 4.5-5.5 | White |
| ER5556 | 0.25 | 4.7-5.5 | White |
Applications
Target Industries
- Automotive
- Aerospace
- General Fabrication
