Air Conditioner Performance Testing System
This automated testing system evaluates the performance of commercial air conditioning units. It features multiple testing stations with integrated control panels and display screens for monitoring test parameters.
Technical Specifications
System Overview
Automated Performance Testing System
This advanced performance testing system is designed for the comprehensive evaluation of commercial air conditioning outdoor units. It features an integrated control cabinet, computer-driven software, and laser barcode scanning for streamlined operation. The system provides real-time monitoring and precise measurement of critical performance parameters, ensuring high-quality output for manufacturing and research environments.
Equipment Components
- Main control cabinet
- Industrial computer system
- Laser barcode scanner
- UPS power supply
- Applicable Models
- 5-20P commercial air conditioner outdoor units
Measurement Capabilities
Temperature Detection
-15 °C
Min Range
150 °C
Max Range
0.5 °C
Accuracy
Pressure Detection
6 MPa
Max Range
0.005 Ratio
Accuracy
Electrical Testing Parameters
| Parameter | Range | Accuracy |
|---|---|---|
| Single Phase Current | 0-45 A | 0.1 A |
| Total Power | 0-30000 W | 5 ‰ |
Technical Standards
Electrical Component Quality
SchneiderSiemensABB
- Operating System
- Windows 7Windows 10
