6-Station 8-Axis Rotary Transfer Machine for Ball Valve Bodies
This rotary transfer machine is designed for machining ball valve bodies, utilizing 6 stations and 8 axes for complex operations in a single setup. It clamps and molds the workpiece at one time, which greatly simplifies the processing steps and improves geometric tolerances.
Technical Specifications
Product Overview
High-Efficiency Rotary Machining
This 6-station 8-axis rotary transfer machine is designed to streamline the production of ball valve bodies by performing complex operations in a single clamping cycle. By eliminating repeated positioning, it significantly improves concentricity and geometric tolerances while dramatically shortening processing times. Built for industrial longevity with a service life exceeding 10 years, it features a fully programmable servo configuration and modular design to support automated production environments.
Performance Metrics
Processing Capability
Technical Specifications
Physical Dimensions & Weight
| Metric | Value |
|---|---|
| Length | 3500 mm |
| Width | 2800 mm |
| Height | 2600 mm |
| Weight | 7200 kg |
- Control Systems Supported
- SchneiderMitsubishiSiemens
Operational Features
Core Workflow Advantages
- Single-clamping molded processing
- Full servo configuration
- Programmable process optimization
- Automatic chip removal system
- Supports integration with robot loading/unloading systems
- Feeding Mode
- Manual / Automatic feeding system
