50 Liter Oil-Lubricated Direct Drive Piston Air Compressor
This 50-liter air compressor utilizes an oil-lubricated, direct-drive piston mechanism. It is designed to provide a reliable source of compressed air for various pneumatic applications.
Technical Specifications
Overview
Professional Performance in a Portable Design
This 50-liter oil-lubricated air compressor is engineered for reliability, utilizing a direct-drive piston mechanism for efficient power transfer. Designed with professional-grade materials, it features a durable cast iron cylinder and an aluminum crankcase for superior heat dissipation. With adjustable pressure settings and integrated thermal protection, it provides a safe and versatile solution for various pneumatic applications.
Technical Specifications
Key Performance Metrics
1.5 kW
Motor Power
198 L/min
Max Air Flow
8 bar
Max Pressure
2,850 rpm
Operating Speed
Electrical Requirements
- Voltage: 127V / 230V
- Frequency: 50Hz
- Model
- CEFL50
Design and Build
Operating Features
- Pressure switch with adjustable cut-in/cut-off settings
- Regulator with pressure gauge
- Easy-open drain valve
- Quick connector included
- Ergonomic carry handle for portability
- Construction Details
- Oil-lubricatedCast iron cylinderAluminum cylinder headThermal protection systemPlastic-coated tank
Compliance
Certifications
CEISO 9001TUVRoHSGS
