24V DC Gear Motor for Vehicle Applications
This DC gear motor is designed for vehicle applications. It features a robust construction and compact gearbox for optimal torque output and speed control.
Technical Specifications
Product Overview
VDF63 Series Performance Overview
The VDF63 is a high-performance DC gear motor specifically engineered for demanding vehicle-based applications. It combines a robust internal construction with a compact gearbox to deliver consistent torque output and precise speed control. Optimized for automotive and robotics integration, this 24V motor ensures reliability and efficiency in various operational environments.
Performance Metrics
Operating Characteristics
24 V
Rated Voltage
48 W
Rated Power
18 N.m
Stalling Torque
Technical Specifications
Performance Table
| Parameter | Value |
|---|---|
| No-load Speed | 33 ±10% RPM |
| No-load Current | 0.8 A max |
| Load Speed | 29 ±10% RPM |
| Load Current | 2.0 A max |
| Stalling Current | 12 A max |
- Rotation Capabilities
- CWCCW
