200 Amp TIG Welder
This welding machine serves as a power source for arc welding, specifically designed for TIG DC welding with HF or LIFT strike capabilities, as well as MMA welding with coated electrodes. Its high-speed and precise adjustment features ensure welds of excellent quality.
Technical Specifications
Product Overview
Industrial Welding Performance
This 200 Amp TIG welder features high-efficiency IGBT inverter technology designed for continuous, heavy-duty factory operations. Supporting both TIG and MMA welding processes, it provides stable performance for stainless steel, alloy, and cast iron fabrication. The unit includes a digital display for precise parameter monitoring and a portable design suitable for both on-site repairs and workshop production.
Technical Specifications
Performance Metrics
200 A
Max Welding Current
60 %
Rated Duty Cycle
60 V
No-Load Voltage
Comparison Table
| Model | Current Range | Input Capacity | Gross Weight |
|---|---|---|---|
| TIG-160A | 10-160A | 6.9KVA | 5.9KG |
| TIG-200A | 10-200A | 8.3KVA | 6.0KG |
| TIG-250A | 10-250A | 10.2KVA | 6.3KG |
- Supported Processes
- TIGMMA
Mechanical Details
- Usable Electrode Range
- 1.6 - 4.0mm
- Packaging Dimensions
- 435 x 260 x 340 mm
Electrical Requirements
- Input Voltage
- 1PH 230V
